D-Link DIR-815 User Manual

DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi
Router with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
To enable the function, click the ENABLE button. Upon that the following settings are available on
the page.
Parameter Description
Port
The number of the port used for data exchange between access
points (routers).
Use multicast for
service data exchange
Move the switch to the right in order to use multicast traffic for
service data exchange between access points (routers). This setting is
needed if the devices which support the smart adjustment function
are located in different subnets. If the switch is moved to the right,
the Multicast TTL and Multicast group address fields are
displayed on the page.
If the switch is moved to the left, broadcast traffic is used for service
data exchange.
Multicast TTL
Specify the TTL (Time to live) parameter value.
Multicast group
address
Specify the address of the multicast group (from the subnet
239.255.0.0/16).
2.4 GHz / 5 GHz
Maximum time of
storing data
The maximum time period (in seconds) during which the access
point (router) stores data on the signal strength of the client located
on its coverage area.
Minimum level of
connection quality
The signal strength upon which the access point (router) starts
scanning other devices in order to find a device with a higher signal
level.
Dead zone
This parameter is used for calculation of the signal strength upon
which the smart adjustment function goes off. If the signal strength
provided by another device is less than the sum of the Minimum
level of connection quality field value and the Dead zone field
value, then the client disconnects from the access point (router). You
can specify the values from -50% to +50%.
Threshold value of
connection quality
The signal strength upon which the access point (router) disconnects
the client from its wireless network regardless of the signal levels of
other devices. This value should not be greater than the value
specified in the field Minimum level of connection quality.
After specifying the needed parameters, click the APPLY button.
To disable the function of smart adjustment of Wi-Fi clients, click the DISABLE button.
Page 150 of 240

D-Link DIR-815 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz Channel 1Nss	65/72.2 Mbps (max)
IEEE 802.11n 20MHz Channel 2Nss	130/144.44 Mbps (max)
IEEE 802.11n 40MHz Channel 1Nss	135/150 Mbps (max)
IEEE 802.11n 40MHz Channel 2Nss	270/300 Mbps (max)
IEEE 802.11a	54 Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 9Mbps - 6Mbps
IEEE 802.11g	54Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 11Mbps - 9Mbps - 6Mbps

Wireless Frequency Range

Frequency Range (802.11g/n)	2.412GHz to 2.462GHz
Frequency Range (802.11a/n)	5.15GHz to 5.825GHz

Transmitter and Antenna

Transmitter Output Power	15dBm +/- 2dB
External Antenna Type	Two (2) undetachable reverse SMA Antennas

Operating Environment

Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	95% maximum (non-condensing)

Weight and Dimensions

Length	6.25 inches (158.87 mm)
Width	4.72 inches (120.04 mm)
Height	1.27 inches (32.18 mm)
