D-Link DIR-815 User Manual

DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi
Router with 3G/LTE Support and USB Port
User Manual
Overview
LED Mode Description
LAN 1-4
Solid green
A device (computer) is connected to the relevant port,
the connection is on.
Blinking green
Data transfer through the relevant LAN port.
When the router is being loaded, the LEDs are blinking
one at a time.
When the firmware is being upgraded, the LEDs are
blinking two at a time.
No light
The cable is not connected to the relevant port.
2.4G WLAN
5G WLAN
Solid green
The router's WLAN of the relevant band is on.
Blinking green
Data transfer through the Wi-Fi network of the relevant
band.
No light
The router's WLAN of the relevant band is off.
WPS
Blinking green
Attempting to add a wireless device via the WPS
function.
No light
The WPS function is not in use.
USB
Solid green
A USB device is connected to the router's USB port.
No light
No USB device.
Page 17 of 240

D-Link DIR-815 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz Channel 1Nss	65/72.2 Mbps (max)
IEEE 802.11n 20MHz Channel 2Nss	130/144.44 Mbps (max)
IEEE 802.11n 40MHz Channel 1Nss	135/150 Mbps (max)
IEEE 802.11n 40MHz Channel 2Nss	270/300 Mbps (max)
IEEE 802.11a	54 Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 9Mbps - 6Mbps
IEEE 802.11g	54Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 11Mbps - 9Mbps - 6Mbps

Wireless Frequency Range

Frequency Range (802.11g/n)	2.412GHz to 2.462GHz
Frequency Range (802.11a/n)	5.15GHz to 5.825GHz

Transmitter and Antenna

Transmitter Output Power	15dBm +/- 2dB
External Antenna Type	Two (2) undetachable reverse SMA Antennas

Operating Environment

Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	95% maximum (non-condensing)

Weight and Dimensions

Length	6.25 inches (158.87 mm)
Width	4.72 inches (120.04 mm)
Height	1.27 inches (32.18 mm)
