D-Link DIR-815 User Manual

DIR-815 AC1200 Wave 2 MU-MIMO Wi-Fi
Router with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Inform Settings
On
Move the switch to the right so the router may send reports (data on
the device and network statistics) to the ACS.
Interval Specify the time period (in seconds) between sending reports.
Auto Configuration Server Settings
URL address The URL address of the ACS provided by the ISP.
Username
The username to connect to the ACS.
Password
The password to connect to the ACS. Click the Show icon ( ) to
display the entered password.
Connection Request Settings
Username
The username used by the ACS to transfer a connection request to
the router.
Password
The password used by the ACS. Click the Show icon ( ) to
display the entered password.
Request port
The port used by the ACS. By default, the port 8999 is specified.
Request path
The path used by the ACS.
When you have configured the parameters, click the APPLY button.
Page 188 of 240

D-Link DIR-815 Specifications

Wireless Signal Rates

IEEE 802.11n 20MHz Channel 1Nss	65/72.2 Mbps (max)
IEEE 802.11n 20MHz Channel 2Nss	130/144.44 Mbps (max)
IEEE 802.11n 40MHz Channel 1Nss	135/150 Mbps (max)
IEEE 802.11n 40MHz Channel 2Nss	270/300 Mbps (max)
IEEE 802.11a	54 Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 9Mbps - 6Mbps
IEEE 802.11g	54Mbps - 48Mbps - 36Mbps - 24Mbps - 18Mbps - 12Mbps - 11Mbps - 9Mbps - 6Mbps

Wireless Frequency Range

Frequency Range (802.11g/n)	2.412GHz to 2.462GHz
Frequency Range (802.11a/n)	5.15GHz to 5.825GHz

Transmitter and Antenna

Transmitter Output Power	15dBm +/- 2dB
External Antenna Type	Two (2) undetachable reverse SMA Antennas

Operating Environment

Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	95% maximum (non-condensing)

Weight and Dimensions

Length	6.25 inches (158.87 mm)
Width	4.72 inches (120.04 mm)
Height	1.27 inches (32.18 mm)
