HDCVI Series DVR User’s Manual
5.3 LAN Mode
For the LAN mode, after you logged in, you can see the main window. See Figure 5-3.
Figure 5-3
This main window can be divided into the following sections.
Section 1: there are six function buttons: Live（chapter 5.4）, playback (chapter 5.10) setup
(chapter 5.8), info (chapter 5.9), alarm (chapter 5.11), and logout (chapter 5.12).
Section 2: There are channel number and one button: Start all. Start all button is to enable/disable
all-channel real-time monitor. Click it the button becomes yellow. See Figure 5-4.
Figure 5-4
Please refer to Figure 5-5 for main stream and extra stream switch information.
Figure 5-5
Section 3: Start dialogue button.
You can click this button to enable audio talk. Click 【▼】 to select bidirectional talk mode. There are
four options: DEFAULT，G711a，G711u and PCM. After you enable the bidirectional talk, the Start talk
button becomes End Talk button and it becomes yellow. See Figure 5-6.
