HDCVI Series DVR User’s Manual
29
Parameters
HCVR7104HE-V2
HCVR7108HE-V2
Port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consuption
≤30W（With power adapeter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×2 45mm（D）×4 5mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.17 HCVR41XXHE-S2 Series
Parameters
HCVR4104HE-S2
HCVR4108HE-S2
HCVR4116HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/
HD1/2CIF/CIF/QCIF
720P(1~15fps)/960H/
D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI ： 1 ～ 25f/s
（ PAL ）；1~30f/s
（NTSC）
CVBS ： 1~25f/s
（ PAL ）；1~30f/s
（NTSC）
HDCVI：1～15f/s（The 1
st
channel supports
25/30f）
CVBS：1~25f/s（PAL）；1~30f/s（NTSC）
Video Frame
Rate
2048Kbps-
4096Kbps，
For 720P: default
setup is 2Mbps ，
max supports
4Mbps.
For 960H: default
setup is 1Mbps ，
max supports
3Mbps.
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps ， max
supports 4Mbps.
For 960H: default setup is 1Mbps ， max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
