Dahua HDCVI series User Manual

HDCVI Series DVR User’s Manual
35
Parameters
HCVR7104HE-S2
HCVR7108HE-S2
Dimensions
Mini 1U case，325mm（W）×2 45mm（D）×4 5mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.22 HCVR41XXHS-S2 Series
Parameters
HCVR4104HS-S2
HCVR4108HS-S2
HCVR4116HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/
2CIF/CIF/QCIF
720P(1-15f/s)/960H/D1/HD1/
2CIF/CIF/QCIF
Video Frame
Rate
HDCVI ： 1 ～ 25f/s
（ PAL ）；1~30f/s
（NTSC）
CVBS ： 1~25f/s
（ PAL ）；1~30f/s
（NTSC）
HDCVI：1～15f/s (The 1
st
channel supports
25/30fps/)
CVBS：1~25f/s（PAL）；1~30f/s（NTSC）
Video Frame
Rate
2048Kbps-
4096Kbps，
For 720P: default
setup is 2Mbps，max
supports 4Mbps.
For 960H: default
setup is 1Mbps，max
supports 3Mbps.
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps ， max
supports 4Mbps.
For 960H: default setup is 1Mbps ， max
supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
16-channel，
BNC port
Network Video
Input
Max 2-channel IPC connections (8M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
