Dahua HDCVI series User Manual

HDCVI Series DVR User’s Manual
17
Parameters
HCVR5104H-V2
HCVR5108H-V2
HCVR5116H-V2
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.10 HCVR51XXHC Series
Parameter
HCVR5104HC
HCVR5108HC
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
N/A
Video monitor
Video Input
4-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
8-CH composite video input:
(NTSC/PAL) BNC (1.0VB
P- P,
B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition
1/4 windows(Optional)
1/4/8/9 windows
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC
)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
