HDCVI Series DVR User’s Manual
196
Parameter
Function
Tour
 Select Tour from the dropdown list.
 Input preset value in the column. Click Add preset button, you
have added one preset in the tour.
 Repeat the above procedures you can add more presets in one
tour.
 Or you can click delete preset button to remove one preset from
the tour.
Pattern
 Select Pattern from the dropdown list.
 You can input pattern value and then click Start button to begin
PTZ movement such as zoom, focus, iris, direction and etc.
Then you can click Add button to set one pattern.
Aux
 Please input the corresponding aux value here.
 You can select one option and then click AUX on or AUX off
button.
Light and
wiper
You can turn on or turn off the light/wiper.
Figure 5-11
5.6 Image
Select one monitor channel video and then click Image button in section 8, the interface is shown as
Figure 5-12.
5.6.1 Image
Here you can adjust its brightness, contrast, hue and saturation. (Current channel border becomes
green).
Or you can click Reset button to restore system default setup.
You can click this icon to
display or hide the PTZ
control platform.
3D Intelligent Positioning
Key
