Specifications SiBE12-908
5 Specifications
1. Specifications
1.1 Indoor Units
50Hz 220-230-240V
Note:
1.
★
: In humidifying operation, the operation sound increases by about 2dB in the indoor unit.
2. The humidifying capacity is 450ml/h under the following condition.
Outdoor air temperature: 7°CDB / 6°CWB
Humidifying hose length: 4.0m
Airflow rate of indoor unit: H tap
Model
CTXU25G2V1B CTXU35G2V1B
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 9.1 (321) 9.8 (346) 10.4 (367) 10.6 (374)
M 7.1 (252) 7.9 (280) 7.7 (270) 8.5 (302)
L 5.2 (182) 6.2 (217) 4.8 (170) 6.4 (226)
SL 3.7 (130) 5.2 (183) 3.5 (125) 5.4 (191)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.09-0.08-0.08 0.10-0.10-0.09 0.12-0.12-0.11 0.13-0.13-0.12
Power Consumption (Rated) W 18 21 26 28
Power Factor % 90.9-97.8-93.8 95.5-91.3-97.2 98.5-94.2-98.5 97.9-93.6-97.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 295×800×215 295×800×215
Packaged Dimensions (H×W×D) mm 274×870×366 274×870×366
Weight kg 9 10
Gross Weight kg 13 14
Operation
Sound
★
H/M/L/SL dBA 38/32/25/22 39/34/28/25 42/34/26/23 42/36/29/26
Sound Power H dBA 54 55 58 58
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D063377 3D063378
Model
CTXU42G2V1B CTXU50G2V1B
Cooling Heating Cooling Heating
Rated Capacity 4.2kW Class 5.0kW Class
Front Panel Color White White
Airflow Rate
m³/min
(cfm)
H 9.1 (321) 11.2 (395) 10.2 (360) 11.0 (388)
M 7.7 (273) 9.4 (333) 8.6 (305) 9.3 (330)
L 6.3 (221) 7.7 (271) 7.0 (246) 7.6 (267)
SL 5.4 (190) 6.8 (240) 6.0 (212) 6.7 (236)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 23 23
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.11-0.11-0.10 0.14-0.14-0.13 0.12-0.12-0.11 0.15-0.14-0.14
Power Consumption (Rated) W 24 30 26 32
Power Factor % 99.2-94.9-100.0 97.4-93.2-96.2 98.5-94.2-98.5 97.0-99.4-95.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 295×800×215 295×800×215
Packaged Dimensions (H×W×D) mm 274×870×366 274×870×366
Weight kg 10 10
Gross Weight kg 14 14
Operation
Sound
★
H/M/L/SL dBA 42/38/33/30 42/38/33/30 43/39/34/31 44/39/34/31
Sound Power H dBA 58 58 59 60
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D063379 3D063380
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
