Daikin 2MXU40GV1B User Manual

SiBE12-908 Specifications
Specifications 6
1.2 Outdoor Units
50Hz 220-230-240V
Note:
1. The data are based on the conditions shown in the table below.
2.
★
: In humidifying operation, the operation sound increases by about 3dB in the outdoor unit.
Model
2MXU40GV1B
Cooling Heating
Capacity kW —
Power Consumption W —
Running Current A —
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 1YC23ABXD
Motor Output W 600
Refrigerant Oil
Model FVC50K
Charge L 0.45
Refrigerant
Type R-410A
Charge kg 1.20
Airflow Rate
m³/min
HH 36 32
H33 32
L30 32
cfm
HH 1,271 1,130
H 1,165 1,130
L 1,059 1,130
Fan
Type Propeller
Motor Output W 50
Starting Current A 4.6
Dimensions (H×W×D) mm 675
×
765
×
285
Packaged Dimensions (H×W×D) mm 739
×
907
×
390
Weight kg 45
Gross Weight kg 49
Operation Sound
★
dBA 47 48
Sound Power dBA 62 —
Piping Connection
Liquid mm
φ
6.4
×
2
Gas mm
φ
9.5
×
2
Drain mm
φ
18
Heat Insulation Both Liquid & Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 30 (for Total of Each Room)
m 15 (for One Room)
Min. Interunit Piping Length m 3 (for One Room)
Amount of Additional Charge g/m 20 (20m or more)
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units)
Drawing No. 3D063328A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m

Daikin 2MXU40GV1B Specifications

General

Brand	Daikin
Model	2MXU40GV1B
Category	Heat Pump
Language	English
