SiBE12-908 Operation Manual
Installation / Operation Manual 82
3.2 AUTO · DRY · COOL · HEAT · FAN Operation
AUTO · DRY · COOL · HEAT · FAN Operation
The air conditioner operates with the operation mode of your choice.
From the next time on, the air conditioner will operate with the same operation mode.
To start operation
1. Press “MODE selector” button and select a operation
mode.
• Each pressing of the button advances the mode setting in sequence.
2. Press “ON/OFF” button.
• “ ” is displayed on the LCD.
• The OPERATION lamp lights up.
To stop operation
3. Press “ON/OFF” button again.
• “ ” disappear from the LCD.
• Then OPERATION lamp goes off.
To change the temperature setting
4. Press “TEMPERATURE adjustment” button.
• The displayed items on the LCD will change whenever either one of the buttons is pressed.
1
5
2, 3
4
AUTO DRY COOL HEAT FAN
Operation mode Multi-monitor lamp
AUTO Blue/Red
DRY Green
COOL Blue
HEAT Red
FAN White
HUMID HEAT
Orange/Yellow
(page 12.)
FRESH AIR SUPPLY
VENTILATION
Lit white for 2 seconds.
After that, return to the
color of selected
operation mode or
change to yellow in a
standby state.
(page 14.)
DRY or FAN mode COOL mode HEAT mode AUTO mode
The temperature setting is not
variable.
18 – 32°C 10 – 30°C 18 – 30°C
Press “ ” button to raise the temperature and
press “ ” button to lower the temperature.
8
To Next Page
