Daikin 2MXU40GV1B User Manual

Indoor Unit SiBE12-908
187 Removal Procedure
1.3 Removal of Front Grille
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1. Removing the service
cover
1
Remove the screw of
the service cover.
Preparation

Remove the front panel
according to the “Removal
of Front Panel”.
2
Pull out the service
cover diagonally down
in the direction of the
arrow.
3
The figure shows the
appearance of the
inside.
2. Removing the front grille
1
Remove the screws
(one each at the right
and left).
(R10343)
Service cover
(R10287)
(R10288)
(R10289)
