Danfoss VACON 1000 User Manual

AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight
[kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-600-066+GAUL
600
6850
440
5020
7610
1600
2796
16250
VACON1000-
ED-640-066+GAUL
640
7310
469
5360
7610
1600
2796
16950
VACON1000-
ED-680-066+GAUL
680
7770
498
5690
9610
1400
2796
18550
Table 29: Nominal Voltage 6900 V, 36-pulse, 6 Power Cells per Phase, 60 Hz
AC Drive type
Low overload rating
110% (Variable tor-
que)
High overload rating
150% (Constant tor-
que)
Cabinet dimensions
Weight [kg]
I
L
[A]
P [kVA]
I
HD
[A]
P [kVA]
W [mm]
D [mm]
H [mm]
VACON1000-
ED-025-069+GAUL
25
290
18
210
2310
1250
2796
3750
VACON1000-
ED-032-069+GAUL
32
380
23
270
2310
1250
2796
3800
VACON1000-
ED-036-069+GAUL
36
430
26
310
2310
1250
2796
3825
VACON1000-
ED-040-069+GAUL
40
470
29
340
2310
1250
2796
3850
VACON1000-
ED-050-069+GAUL
050
590
36
430
2310
1250
2796
3875
VACON1000-
ED-060-069+GAUL
060
710
44
520
2310
1250
2796
3900
VACON1000-
ED-065-069+GAUL
065
770
47
560
2310
1250
2796
3925
VACON1000-
ED-070-069+GAUL
070
830
51
600
2310
1250
2796
3950
VACON1000-
ED-080-069+GAUL
080
950
58
690
2710
1250
2888
5300
VACON1000-
ED-100-069+GAUL
100
1190
73
870
2710
1250
2888
5350
VACON1000-
ED-120-069+GAUL
120
1430
88
1050
2710
1250
2888
5400
VACON1000-
ED-140-069+GAUL
140
1670
102
1210
2710
1250
2888
5450
VACON1000-
ED-150-069+GAUL
150
1790
110
1310
3010
1250
2888
6100
VACON1000-
ED-160-069+GAUL
160
1910
117
1390
3010
1250
2888
6150
