Illustration 43: Terminals in the Standalone Cabinet
A
Output power terminal
B
Motor connection terminal
C
Power connection terminal
D
Grounding connection between cabinets
E
System grounding terminal
F
Busbars for connecting power cells in series
G
Output neutral point terminal
H
Transformer input terminal
I
Transformer output terminal
6.4.2 Terminal Locations in the Line-up Cabinet
A
B
C
D
e30bi673.10
Illustration 44: Terminals in the Control and Power Cell Cabinets
AQ363633621020en-000201 / 172F311748 | Danfoss A/S © 2021.06
Electrical Installation
VACON® 1000
Operating Guide
