Danfoss VLT CDS 803 Programming Guide

1. Press [Menu] until indicator in display is placed
above Main Menu.
2.
Press [
▲
] [
▼
] to browse through the parameter
groups.
3. Press [OK] to select a parameter group.
4.
Press [
▲
] [
▼
] to browse through the parameters in
the specic group.
5. Press [OK] to select the parameter.
6.
Press [
▲
] [
▼
] to set/change the parameter value.
Press [Back] to go back one level.
2.4 Quick Transfer of Parameter Settings
between Multiple Frequency Converters
Once the set-up of a frequency converter is complete,
Danfoss recommends storing the data in the LCP or on a
PC via MCT 10 Set-up Software tool.
Data transfer from frequency converter to LCP:
WARNING
Stop the compressor before performing this operation.
1. Go to parameter 0-50 LCP Copy.
2. Press [OK].
3. Select [1] All to LCP.
4. Press [OK].
Connect the LCP to another frequency converter and copy
the parameter settings to this frequency converter as well.
Data transfer from LCP to frequency converter:
WARNING
Stop the compressor before performing this operation.
1. Go to parameter 0-50 LCP Copy.
2. Press [OK].
3. Select [2] All from LCP.
4. Press [OK].
2.5
Readout and Programming of Indexed
Parameters
Select the parameter, press [OK], and press [
▲
]/[
▼
] to scroll
through the indexed values. To change the parameter
value, select the indexed value and press [OK]. Change the
value by pressing [
▲
]/[
▼
]. Press [OK] to accept the new
setting. Press [Cancel] to abort. Press [Back] to leave the
parameter.
2.6
Initialize the Frequency Converter to
Default Settings in 2 Ways
Recommended initialization (via
parameter 14-22 Operation Mode)
1. Select parameter 14-22 Operation Mode.
2. Press [OK].
3. Select [2] Initialisation and Press [OK].
4. Cut o the mains supply and wait until the
display turns o.
5. Reconnect the mains supply - the frequency
converter is now reset.
Except the following parameters:
•
Parameter 1-06 Clockwise Direction
•
Parameter 8-30 Protocol
•
Parameter 8-31 Address
•
Parameter 8-32 Baud Rate
•
Parameter 8-33 Parity / Stop Bits
•
Parameter 8-35 Minimum Response Delay
•
Parameter 8-36 Maximum Response Delay
•
Parameter 8-37 Maximum Inter-char delay
•
Parameter 15-00 Operating hours to
parameter 15-05 Over Volt's
•
Parameter 15-03 Power Up's
•
Parameter 15-04 Over Temp's
•
Parameter 15-05 Over Volt's
•
Parameter 15-30 Alarm Log: Error Code
•
Parameter group 15-4* Drive identication
parameters
2-nger initialization
1. Power o the frequency converter.
2. Press [OK] and [Menu].
3. Power up the frequency converter while still
pressing the keys above for 10 s.
4. The frequency converter is now reset, except the
following parameters:
•
Parameter 15-00 Operating hours
•
Parameter 15-03 Power Up's
•
Parameter 15-04 Over Temp's
•
Parameter 15-05 Over Volt's
•
Parameter group 15-4* Drive identication
parameters
Initialization of parameters is conrmed by AL80 in the
display after the power cycle.
How to Program Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 17
2 2
