Danfoss VLT CDS 803 Programming Guide

Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
14-90 Fault Level [4] Trip w. delayed reset All set-ups FALSE - Uint8
5.1.12 15-** Drive Information
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
15-0* Operating Data
15-00 Operating hours 0 h 1 set-up TRUE 74 Uint32
15-01 Running Hours 0 h 1 set-up TRUE 74 Uint32
15-03 Power Up's 0 N/A 1 set-up TRUE 0 Uint32
15-04 Over Temp's 0 N/A 1 set-up TRUE 0 Uint16
15-05 Over Volt's 0 N/A 1 set-up TRUE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset 1 set-up TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset 1 set-up TRUE - Uint8
15-08 Number of Starts 0 N/A All set-ups FALSE 0 Uint32
15-09 Number of Auto Resets 0 N/A All set-ups FALSE 0 Uint32
15-3* Alarm Log
15-30 Alarm Log: Error Code 0 N/A 1 set-up TRUE 0 Uint8
15-31 InternalFaultReason 0 N/A 1 set-up TRUE 0 Int16
15-4* Drive Identication
15-40 FC Type 0 N/A 1 set-up FALSE 0 VisStr[6]
15-41 Power Section 0 N/A 1 set-up FALSE 0 VisStr[20]
15-42 Voltage 0 N/A 1 set-up FALSE 0 VisStr[20]
15-43 Software Version 0 N/A 1 set-up FALSE 0 VisStr[20]
15-44 Ordered TypeCode 0 N/A 1 set-up FALSE 0 VisStr[40]
15-45 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Drive Ordering No 0 N/A 1 set-up FALSE 0 VisStr[8]
15-48 LCP Id No 0 N/A 1 set-up FALSE 0 VisStr[21]
15-49 SW ID Control Card 0 N/A 1 set-up FALSE 0 VisStr[21]
15-50 SW ID Power Card 0 N/A 1 set-up FALSE 0 VisStr[21]
15-51 Drive Serial Number 0 N/A 1 set-up FALSE 0 VisStr[10]
15-53 Power Card Serial Number 0 N/A 1 set-up FALSE 0 VisStr[20]
15-57 File version 0 N/A 1 set-up FALSE 0 Uint8
15-59 File name 0 N/A 1 set-up FALSE 0 VisStr[16]
5.1.13 16-** Data Readouts
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
16-0* General Status
16-00 Control Word 0 N/A 1 set-up TRUE 0 Uint16
16-01 Reference [Unit] 0 ReferenceFeedbackUnit 1 set-up TRUE -3 Int32
16-02 Reference [%] 0 % 1 set-up TRUE -1 Int16
16-03 Status Word 0 N/A 1 set-up TRUE 0 Uint16
16-05 Main Actual Value [%] 0 % 1 set-up TRUE -2 Int16
16-09 Custom Readout 0 CustomReadoutUnit 1 set-up TRUE -2 Int32
16-1* Motor Status
16-10 Power [kW] 0 kW 1 set-up TRUE -3 Uint32
16-11 Power [hp] 0 hp 1 set-up TRUE -3 Uint32
Parameter Lists Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 83
5 5
