Danfoss VLT CDS 803 Programming Guide

4.2 Alarm Words
Bit Hex Dec
Parameter 16-90 Alarm
Word
Parameter 16-91 Alarm
Word 2
Parameter 16-97 Alarm
Word 3
0 1 1 0 0 0
1 2 2 Pwr. Card Temp 0 0
2 4 4 Earth Fault 0 0
3 8 8 0 0 0
4 10 16 Ctrl. Word TO 0 ORM Fault
5 20 32 Overcurrent 0 0
6 40 64 0 0 0
7 80 128 Motor Th. Over 0 0
8 100 256 Motor ETR Over 0 0
9 200 512 Inverter Overld. 0 0
10 400 1024 DC under Volt Start Failed 0
11 800 2048 DC over Volt. 0 0
12 1000 4096 Short Circuit External Interlock 0
13 2000 8192 0 0 0
14 4000 16384 Mains ph. loss 0 0
15 8000 32768 AMA Not OK 0 0
16 10000 65536 Live Zero Error 0 0
17 20000 131072 Internal Fault 0 0
18 40000 262144 0 0 0
19 80000 524288 U phase Loss 0 0
20 100000 1048576 V phase Loss 0 0
21 200000 2097152 W phase Loss 0 0
22 400000 4194304 0 0 0
23 800000 8388608 Control Voltage Fault 0 0
24 1000000 16777216 0 0 0
25 2000000 33554432 0 0 0
26 4000000 67108864 0 0 0
27 8000000 134217728 0 0 0
28 10000000 268435456 0 0 0
29 20000000 536870912 Drive Initialised 0 0
30 40000000 1073741824 0 0 0
31 80000000 2147483648 0 0 0
Troubleshooting Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 69
4 4
