Danfoss VLT CDS 803 Programming Guide

6-92 Terminal 42 Digital Output
Select the function of Terminal 42 as an analog current output.
See also parameter 6-90 Terminal 42 Mode. See
parameter 5-40 Function Relay for description of the choices.
Option: Function:
[25] Reverse
[26] Bus OK
[35] External
Interlock
[36] Control word
bit 11
[37] Control word
bit 12
[41] Below
reference, low
[42] Above ref,
high
[44] Oil boost
active
[45] Bus Control
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital
output A
[81] SL digital
output B
[82] SL digital
output C
[83] SL digital
output D
[160] No alarm
[161] Running
reverse
[165] Local ref.
active
[166] Remote ref.
active
[167] Start
command
activ
[168] Drive in hand
mode
[169] Drive in auto
mode
6-93 Terminal 42 Output Min Scale
Range: Function:
0 %* [0 - 200 %] Scale for the minimum output (0
mA or 4 mA) of the analog signal
at terminal 42. Set the value to be
the percentage of the full range of
the variable selected in
parameter 6-91 Terminal 42 Analog
Output.
6-94 Terminal 42 Output Max Scale
Range: Function:
100 %* [0 - 200 %] Scale for the maximum output (20
mA) of the scaling at terminal 42.
Set the value to be the percentage
of the full range of the variable
selected in parameter 6-91 Terminal
42 Analog Output.
(mA)
0%
20
0/4
100%
Current
Analog
output
Min Scale
par. 6-93
Variable
for
output
example:
Power
Analog
Output
Max Scale
par. 6-94
130BB772.10
Illustration 3.10 Output
Maximum Scale
6-96 Terminal 42 Output Bus Control
Range: Function:
0* [0 - 16384 ] Hold the analog output at terminal
42 if controlled by bus.
3.8 Main Menu - Communications and
Options - Group 8
3.8.1 8-0* General Settings
8-01 Control Site
This parameter overrules settings in parameter 8-50 Coasting
Select to parameter 8-56 Preset Reference Select.
Option: Function:
[0] * Digital and
ctrl.word
Control by using both digital input
and control word.
[1] Digital only Control by using digital inputs only.
[2] Controlword
only
Control by using control word only.
Parameters
VLT
®
Compressor Drive CDS 803
40 Danfoss A/S © 06/2019 All rights reserved. MG18P202
