Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
4-4* Adj. Warnings 2
4-40 Warning Freq. Low 30 Hz All set-ups TRUE -1 uint16
4-41 Warning Freq. High 200 Hz All set-ups TRUE -1 uint16
4-5* Adj. Warnings
4-50 Warning Current Low 0 A All set-ups TRUE -2 Uint32
4-51 Warning Current High ExpressionLimit All set-ups TRUE -2 Uint32
4-54 Warning Reference Low 0 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 6010 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High 6010 ProcessCtrlUnit All set-ups TRUE -3 Int32
4-58 Missing Motor Phase Function [1] On All set-ups FALSE - Uint8
4-6* Speed Bypass
4-61 Bypass Speed From [Hz] 0 Hz All set-ups TRUE -1 Uint16
4-63 Bypass Speed To [Hz] 0 Hz All set-ups TRUE -1 Uint16
5.1.7 5-** Digital In/Out
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
5-0* Digital I/O mode
5-00 Digital Input Mode [0] PNP 1 set-up FALSE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 Digital Input [0] No operation All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input [2] Coast inverse All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input [12] Jog All set-ups TRUE - Uint8
5-4* Relays
5-40 Function Relay ExpressionLimit All set-ups TRUE - Uint8
5-41 On Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-42 O Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-5* Pulse Input
5-50 Term. 29 Low Frequency 20 Hz All set-ups TRUE 0 Uint32
5-51 Term. 29 High Frequency 32000 Hz All set-ups TRUE 0 Uint32
5-52 Term. 29 Low Ref./Feedb. Value 0 N/A All set-ups TRUE -3 Int32
5-53 Term. 29 High Ref./Feedb. Value 50 All set-ups TRUE -3 Int32
5-9* Bus Controlled
5-90 Digital & Relay Bus Control 0 N/A All set-ups TRUE 0 Uint32
Parameter Lists Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 79
5 5
