5.1.14 20-** Drive Closed Loop
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
20-0* Feedback
20-00 Feedback 1 Source [0] No function All set-ups TRUE - Uint8
20-01 Feedback 1 Conversion [0] Linear All set-ups TRUE - Uint8
20-03 Feedback 2 Source [0] No function All set-ups TRUE - Uint8
20-04 Feedback 2 Conversion [0] Linear All set-ups TRUE - Uint8
20-2* Feedback/Setpoint
20-20 Feedback Function [3] Minimum All set-ups TRUE - Uint8
20-8* PI Basic Settings
20-81 PI Normal/ Inverse Control [0] Normal All set-ups TRUE - Uint8
20-83 PI Start Speed [Hz] 0 Hz All set-ups TRUE -1 Uint16
20-84 On Reference Bandwidth 5 % All set-ups TRUE 0 Uint8
20-9* PI Controller
20-91 PI Anti Windup [1] On All set-ups TRUE - Uint8
20-93 PI Proportional Gain 0.50 N/A All set-ups TRUE -2 Uint16
20-94 PI Integral Time 20 s All set-ups TRUE -2 Uint32
20-97 PI Feed Forward Factor 0 % All set-ups TRUE 0 Uint16
5.1.15 28-** Compressor Functions
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
28-0* Short Cycle Protection
28-00 Short Cycle Protection [1] Enabled All set-ups TRUE - Uint8
28-01 Interval between Starts 300 s All set-ups TRUE 0 Uint16
28-02 Minimum Run Time 12 s All set-ups TRUE 0 Uint16
28-1* Oil Return Management
28-10 Oil Return Management [1] On All set-ups FALSE - Uint8
28-11 Low Speed Running Time 120 min All set-ups TRUE 70 Uint16
28-12 Fixed Boost Interval 24 h All set-ups TRUE 0 Uint8
28-13 Boost Duration 60 s All set-ups FALSE 0 Uint16
28-15 ORM Min Speed Limit (Hz) 80 Hz All set-ups TRUE 0 Uint16
28-17 ORM Boost Speed (Hz) 120 Hz All set-ups TRUE 0 Uint16
28-4* Anti-reverse Protection at Stop
28-40 Reverse Protection Control [1] Enabled All set-ups TRUE - Uint8
28-6* Compressor Readouts
28-60 RPS 0 /s All set-ups FALSE -1 uint16
Parameter Lists Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 85
