Danfoss VLT CDS 803 Programming Guide

5.1.10 13-** Smart Logic
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
13-0* SLC Settings
13-00 SL Controller Mode [0] O 1 set-up TRUE - Uint8
13-01 Start Event [39] Start command 1 set-up TRUE - Uint8
13-02 Stop Event [40] Drive stopped 1 set-up TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC 1 set-up TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand [0] Disabled 1 set-up TRUE - Uint8
13-11 Comparator Operator [1] Approx.Equal (~) 1 set-up TRUE - Uint8
13-12 Comparator Value 0 N/A 1 set-up TRUE -3 Int32
13-2* Timers
13-20 SL Controller Timer 0 s 1 set-up TRUE -2 Uint32
13-4* Logic Rules
13-40 Logic Rule Boolean 1 [0] False 1 set-up TRUE - Uint8
13-41 Logic Rule Operator 1 [0] Disabled 1 set-up TRUE - Uint8
13-42 Logic Rule Boolean 2 [0] False 1 set-up TRUE - Uint8
13-43 Logic Rule Operator 2 [0] Disabled 1 set-up TRUE - Uint8
13-44 Logic Rule Boolean 3 [0] False 1 set-up TRUE - Uint8
13-5* States
13-51 SL Controller Event [0] False 1 set-up TRUE - Uint8
13-52 SL Controller Action [0] Disabled 1 set-up TRUE - Uint8
5.1.11 14-** Special Functions
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
14-0* Inverter Switching
14-01 Switching Frequency 5.0 kHz All set-ups TRUE - Uint8
14-03 Overmodulation [1] On All set-ups FALSE - Uint8
14-1* Mains On/O
14-10 Mains Failure [0] No function All set-ups FALSE - Uint8
14-11 Mains Voltage at Mains Fault ExpressionLimit All set-ups TRUE 0 Uint16
14-12 Function at Mains Imbalance [1] Warning 1 set-up TRUE - Uint8
14-2* Reset Functions
14-20 Reset Mode [10] Automatic reset x 10 All set-ups TRUE - Uint8
14-21 Automatic Restart Time 30 s All set-ups TRUE 0 Uint16
14-22 Operation Mode [0] Normal operation 1 set-up TRUE - Uint8
14-24 Trip Delay at Current Limit 60 s All set-ups TRUE 0 Uint8
14-29 Service Code 0 N/A 1 set-up TRUE 0 Uint32
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain 100 All set-ups FALSE 0 Uint16
14-31 Current Lim Ctrl, Integration Time 0.016 s All set-ups FALSE -3 Uint16
14-32 Current Lim Ctrl, Filter Time 5.0 ms All set-ups FALSE -4 Uint16
14-5* Environment
14-55 Output Filter [0] No Filter 1 set-up FALSE - Uint8
14-6* Auto Derate
14-61 Function at Inverter Overload Trip All set-ups FALSE - Uint8
14-63 Min Switch Frequency [2] 2.0 kHz 1 set-up FALSE - Uint8
14-9* Fault Settings
Parameter Lists
VLT
®
Compressor Drive CDS 803
82 Danfoss A/S © 06/2019 All rights reserved. MG18P202
55
