Danfoss VLT CDS 803 Programming Guide

5.1.3 1-** Load and Motor
Param
eter
numb
er
Parameter description Default value 2 set-up Change during
operation
Conversion
index
Type
1-0* General Settings
1-00 Conguration Mode [0] Open Loop All set-ups TRUE - Uint8
1-01 Motor Control Principle [1] VVC+ All set-ups FALSE - Uint8
1-06 Clockwise Direction [0] Normal 1 set-up FALSE - Uint8
1-1* Motor Selection
1-13 Compressor Selection ExpressionLimit 2 set-ups TRUE - Uint8
1-2* Motor Data
1-20 Motor Power ExpressionLimit All set-ups FALSE - Uint8
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque ExpressionLimit All set-ups FALSE -1 Uint32
1-29 Automatic Motor Adaption (AMA) [0] O All set-ups FALSE - Uint8
1-4* Adv. Motor Data II
1-42 Motor Cable Length 10 m All set-ups FALSE 0 Uint8
1-43 Motor Cable Length Feet 33 ft All set-ups FALSE 0 Uint16
1-44 d-axis Inductance Sat. (LdSat) ExpressionLimit All set-ups FALSE -6 Int32
1-45 q-axis Inductance Sat. (LqSat) ExpressionLimit All set-ups FALSE -6 Int32
1-48 Current at Min Inductance for d-axis 70 % All set-ups FALSE 0 Int16
1-49 Current at Min Inductance for q-axis 70 % All set-ups FALSE 0 Uint16
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed 100 % All set-ups TRUE 0 Uint16
1-52 Min Speed Normal Magnetising [Hz] 0 Hz All set-ups TRUE -1 Uint16
1-55 U/f Characteristic - U ExpressionLimit All set-ups FALSE -1 Uint16
1-56 U/f Characteristic - F ExpressionLimit All set-ups FALSE -1 Uint16
1-6* Load Depen. Setting
1-66 Min. Current at Low Speed 50 % All set-ups TRUE 0 Uint32
1-7* Start Adjustments
1-70 Start Mode [1] Parking All set-ups TRUE - Uint8
1-71 Start Delay 60 s All set-ups TRUE -1 Uint8
1-72 Start Function [2] Coast/delay time All set-ups TRUE - Uint8
1-73 Flying Start [1] Enabled Always All set-ups TRUE - Uint8
1-75 Start Speed [Hz] 100 Hz All set-ups TRUE -1 Uint16
1-78 Compressor Start Min. Speed [Hz] 29 Hz All set-ups TRUE -1 Uint16
1-79 Compressor Start Max Time to Trip 3 s All set-ups TRUE -1 Uint8
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1-82 Min Speed for Function at Stop [Hz] 0 Hz All set-ups TRUE -1 Uint16
1-87 Compressor Min. Speed for Trip [Hz] 28 Hz All set-ups TRUE -1 Uint16
1-9* Motor Temperature
1-90 Motor Thermal Protection [4] ETR trip 1 All set-ups TRUE - Uint8
1-93 Thermistor Source [0] None All set-ups FALSE - Uint8
Table 5.2
Parameter Lists Programming Guide
MG18P202 Danfoss A/S © 06/2019 All rights reserved. 77
