Product Reference Guide 101
Chapter 11
Data Editing
Data Editing Overview
When a barcode is scanned, additional information can be sent to the host computer
along with the barcode data. This combination of barcode data and supplementary user-
defined data is called a “message string.” The features in this chapter can be used to build
specific user-defined data into a message string.
There are several types of selectable data characters that can be sent before and after
scanned data. You can specify if they should be sent with all symbologies, or only with
specific symbologies. Figure 3 shows the available elements you can add to a message
string:
Figure 3. Breakdown of a Message String
CAUTION
It is not recommended to use these features with IBM interfaces.
NOTE
Additional advanced editing is available. See the Advanced Formatting fea-
tures in the Datalogic Aladdin Configuration Application or contact
Technical
Support on page 3
for more information.
Prefix SuffixAIM IDLabel ID Label IDBar Code Data
00 - 20 Characters (ASCII)
Label ID Transmission:
Enable this option to
transmit the Label ID you
configure for the scanned
symbology.
AIM ID: This function is used to identify and display the
common label identifier for its symbology. When enabled,
this ID code will be transmitted before the scanned bar
code data.
OR...
To Next Page
