ABC Codabar

Product Reference Guide 247

ABC Codabar — cont.

ABC Codabar Force Concatenation

Forces labels starting or ending with D to be concatenated.

ENTER/EXIT PROGRAMMING MODE

ABC Codabar Force Concatenation = Disable

ABC Codabar Force Concatenation = Enable

DEFAULT

Default Chapter3
