Dell 5110cn - Color Laser Printer User Manual

Print media source
Print side
Page orientation
Standard 500-sheet tray
Optional 500-sheet tray module or 1000-
sheet module
Face up
Letterhead at the back of
the tray
Multipurpose feeder
Face down
Letterhead enters the
printer first.
Multipurpose Feeder
Capacity
The maximum stack height is 15 mm (0.6 in.). The multipurpose feeder can hold approximately:
150 sheets or a stack less than 15 mm (60 g/m
2
to 216 g/m
2
) paper.
Print Media Dimensions
The multipurpose feeder accepts print media within the following dimensions:
Width -- 88.9 mm to 220 mm
Length -- 139.7 mm to 355.6 mm

Dell 5110cn - Color Laser Printer Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Processor Speed	400 MHz
Print Speed (Black)	35 ppm
