2.
3.
Click Apply New Settings.4.
NOTE: The SMTP server will display Connection in Progress until an error occurs.
Determining the Wireless Network Settings
You need to know the settings for the wireless network to set up the wireless printer. For details of the
settings, contact your network administrator.
Specifies the name that identifies the wireless network. Up to 32 alphanumeric
characters.
Specifies the network type from Ad-hoc or Infrastructure.
Selects the security method from No security, WEP, WPA-PSK TKIP and WPA-
PSK AES.
Specifies the transmit key from the list.
Specified the WEP key set used through the wireless network only when WEP
is selected for Security.
Specifies the pass phrase of alphanumeric characters from 8 to 63 bytes long
only when WPA-PSK is selected for Encryption.
NOTE: To set WPA2-PSK as security, select WPA-PSK AES.
Wireless Installation using USB connection
NOTE: The optional multi protocol card with the Wireless Printer Adapter attached must be installed
on the printer.
Scene 1. Install a printer to the already-operating wireless network (When wireless setting is already set to
your computer)
Insert the Drivers and Utilities CD into your computer.1.
The Drivers and Utilities CD should launch the installation software automatically.
If the CD does not automatically launch, click Start Run, type D:\Setup.exe (where D is the drive
letter of your CD), and then click OK.
2.
NOTE: For Windows Vista, click Continue when the User Account Control dialog box appears.
Select the Network Installation option button, and then click Next.3.
Select the Configure Wireless Printer using a USB connection (Recommended) option button,
and then click Next.
4.
5.
To Next Page
