Figure 35. Installing a storage sled
a. dotted line on storage sled
b. sled lock (2)
Next steps
Turn on the compute sled(s) to which the storage sled is mapped. The storage sled turns on.
Related references
Safety instructions on page 33
Related information
Removing a storage sled on page 37
Inside the system
CAUTION:
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or
telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by
your warranty. Read and follow the safety instructions that are shipped with your product.
NOTE: Components that are hot-swappable are marked orange, and touch points on the components are marked blue.
40 Installing and removing PowerEdge FX2/FX2s enclosure components
