Figure 44. Removing and installing the cooling-fan cage
a. screw (6)
b. cooling-fan cage
Figure 45. Cooling-fan cage top view
a. screw location (6)
Next steps
Install the cooling-fan cage.
Related tasks
Installing the cooling-fan cage on page 55
Removing the system cover on page 34
Removing a cooling fan on page 52
Installing the cooling-fan cage
Prerequisites
CAUTION:
Many repairs may only be done by a certified service technician. You should only perform
troubleshooting and simple repairs as authorized in your product documentation, or as directed by the online or
telephone service and support team. Damage due to servicing that is not authorized by Dell is not covered by
your warranty. Read and follow the safety instructions that are shipped with your product.
Installing and removing PowerEdge FX2/FX2s enclosure components 55
