● PCI Express* Base Specification Revision 3.0
● Integrated Serial ATA host controller, supports data transfer rates of up to 6 Gb/s on all ports.
● xHCI USB controller with SuperSpeed USB 3.0 ports
● Direct Media Interface
● Serial Peripheral Interface
● Enhanced Serial Peripheral Interface
● Flexible I/O - Allows some high speed I/O signals to be configured as PCIe root ports, PCIe uplink for use with certain PCH
SKUs, SATA (and sSATA), or USB 3.0.
● General Purpose Input Output (GPIO)
● Low Pin Count interface, interrupt controller, and timer functions
● System Management Bus Specification, Version 2.0
● Integrated Clock Controller / Real Time Clock Controller
● Intel® High Definition Audio and Intel® Smart Sound Technology
● Integrated 10/1 Gb Ethernet
● Integrated 10/100/1000 Mbps Ethernet MAC
● Supports Intel® Rapid Storage Technology Enterprise
● Supports Intel® Active Management Technology and System Platform Services
● Supports Intel® Virtualization Technology for Directed I/O
● Supports Intel® Trusted Execution Technology
● JTAG Boundary Scan support
● Intel® QuickAssist Technology
● Intel® Trace Hub for debug
For more information, visit
Intel.com
System memory
The system supports DDR4 registered DIMMs (RDIMMs) and load reduced DIMMs (LRDIMMs). System memory holds the
instructions that are executed by the processor.
NOTE: MT/s indicates DIMM speed in MegaTransfers per second.
Memory bus operating frequency can be 2133 MT/s, 2400 MT/s, or 2666 MT/s depending on the following factors:
● DIMM type (RDIMM or LRDIMM)
● Number of DIMMs populated per channel
● System profile selected (for example, Performance Optimized, Custom, or Dense Configuration Optimized)
● Maximum supported DIMM frequency of the processors
Your system contains 24 memory sockets split into two sets of 12 sockets, one set per processor. Each 12-sockets is organized
into six channels. Two sockets per channel with the release tabs of the first socket marked white and the second socket black.
NOTE: DIMMs in sockets A1 to A12 are assigned to processor 1 and DIMMs in sockets B1 to B12 are assigned to processor
2.
Table 17. Maximum memory module
Frequency supported Processors
2133 31xx series
2400 41xx series
2400 51xx series
2666 61xx series
Memory channels are organized as follows:
Table 18. Memory channels
Processor Channel 0 Channel 1 Channel 2 Channel 3 Channel 4 Channel 5
CPU 1 Slots A1, A7 Slots A2, A8 Slots A3, A9 Slots A4, A10 Slots B5, A11 Slots A6, A12
102 Technology and components
