Next steps
Install the optical drive.
Installing optical drive
Steps
1. Slide the optical drive to the system, until the locks into place.
2. Connect the optical drive cable on the optical drive.
3. Install system cover and front bezel if applicable.
Air shroud
Removing air shroud
Prerequisites
CAUTION:
Never operate your system with the air shroud removed. The system may get overheated quickly, resulting in
shutdown of the system and loss of data.
1. If installed, remove the full length PCIe cards.
2. If applicable, remove the GPU cards.
Steps
Hold the shroud at both ends and lift it away from the system.
Disassembly and reassembly 31
