Installing right control panel
Steps
1. Route the control panel cable and VGA cable through the side wall of the system.
2. Align the control panel with the control panel slot on the system and attach the control panel to the system.
3. Connect the VGA cable to the system board.
4. Connect the control panel cable to the system board and secure it using cable latch.
5. Using Phillips #1 screwdriver, install the screws(6) that secure the control panel and cable tube to the system.
Next steps
1. Install cooling fan assembly.
2. Install air shroud.
GPU Host Card Installation
This section describes the following hardware installation processes
Alternate Riser Installation
This section describes the installation of the alternate riser to the system board. The alternate riser 3 is required for the PCIe X
16 lane operating with the NVIDIA Quadro K4200 GPU. This provides the best performance for this card.
66 Disassembly and reassembly
