Dell PowerEdge T20 User Manual

Drives
Up to four 3.5 inch internal, cabled SATA, or SATA SSD
drives and one optical disk drive (optional).
Two 3.5 inch and two 2.5 inch (optional), internal, cabled
SATA, or SATA SSD drives.
Six hard-drive systems Up to four 3.5 inch and two 2.5 inch (optional), internal,
cabled SATA, or SATA SSD drives.
NOTE: If you install more than four hard drives, you
need to get an additional SATA controller card,
SATA cables (minimum 1.6 ft) and power extension
cables.
Optical drive Optional slim 9.5 mm SATA DVD-ROM drive or DVD+/-RW
drive.
NOTE: External optical drives can be connected
through USB ports.
Connectors
Back
NIC Two 10/100/1000 Mbps
Serial 9-pin, DTE, 16550-compatible
USB Four 4-pin USB 2.0-compliant
Two 4-pin USB 3.0-compliant
Video Two 15-pin VGA display ports
Front
USB Two 4-pin USB 2.0-compliant
Two 4-pin USB 3.0-compliant
Video
Video type Integrated Intel HD P4600 Graphics
NOTE: This is available only on select Intel Xeon
processors.
Environmental Specifications
Temperature
Operating 5 °C to 35°C (41 °F to 95 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
Relative Humidity (maximum)
78

Dell PowerEdge T20 Specifications

General

Chipset	Intel C226
Storage Capacity	Up to 12TB
Power Supply	290W
Form Factor	Tower
Processor	Intel Xeon E3-1225 v3
Memory	Up to 32GB DDR3
Storage Options	4 x 3.5-inch SATA
RAID Support	RAID 0, 1, 5, 10
Expansion Slots	1 x PCIe x16
Network	Gigabit Ethernet
USB Ports	4 x USB 3.0
Weight	11 kg
Operating System Support	Windows Server, Red Hat Enterprise Linux
CPU Options	Intel Xeon E3-1200 v3 series, Intel Core i3, Intel Pentium
