If speakers with
an
impedance lowerthan specified
(for example 4 O/ohms speakers)
are
used for
an
extended period
of
time
with
the
volume turned
up high, the temperature may rise, activating the
protection circuit.
When the protection circuit
is
activated, the
speaker output
is
shut off and the power indicator
flashes red. If this happens, unplug the power
cord, then check the speaker cable
and
input cable
connections. If the set
is
extremely hot, wait for it
to
cool off
and
improve ventilation around it. Once
this is done, plug the power cord
back
in
and turn
the set's power back on.
If the protection circuit
is
activated again even
though there are
no
problems
in
the ventilation
around the set nor
in
the connections, the set may
be damaged.
Turn
the power off, then contact a
DENON service center.
...
-·~~.~aplug
4
'fum
the speaker terminal
clockwise to tighten it.
Tighten the speaker terminal firmly before
inserting the banana plug.
Carefully check the left
(L)
and right
(R)
channels
and + (red) and -
(black)
polarities on the speakers
being connected to the AVR-1708, and be sure
to
interconnect the channels and polarities correctly.
2
Turn
the speaker terminal
counterclockwise to loosen
it.
Connecting
the
Speaker Cables
3
Insert the speaker cable's
core wire to the hilt into the
speaker terminal.
1
Peel
off
about 0.03 ftllO
IDOl
of
sheathing from the tip
of
thespeakercable,theneither
twist the core
wire tightly
or
terminate it.
'~[,h4
• Use speakers with
an
impedance
of
6
to
16
O/ohms. When using front A
and
B speakers
simultaneously, use speakers
with
an
impedance
of
8 to
16
O/ohms.
• Connect the speaker cables
in
such a way that
they do not stick out
of
the speaker terminals.
The protection circuit may be activated if the core
wires touch the rear panel or if the + and - sides
touch each other
(Gf'
"Protection circuit").
• Never touch the speaker terminals while the
power supply
is
connected. Doing so could result
in electric shock.
Center speaker
ZONE2 speakers
DO
<=>
"---
ZONE2
---
iii
0
Front
s:e
akers
I
iii
0
<=>
<=>
D0
ISurround speakers I
Front speakers
A
......,-==~r------------I-
-
-I-
.........
==""""I""'.w
Example: 5.1-channels (FRONT A+B) and
lONE2
use
*
L:
Left
R:
Right
When using just one surround back speaker, connect it to the left channel (SBl).
'N,h4
By
default, the AVR-1708's "Amp Assign" setting
is
set to
"lONEr
To
use
as
the surround back speaker
for the main zone, change the "Amp Assign" setting
lGf'page
27).
I Subwoofer I
(J
~.
Subwoofer
~
with built-in
.0
amplifier
~IN
Ul
ll>
"
"
I
9
To Next Page
