Denon AVR-3312 Service Manual

107
LAEVEL DIAGRAM
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+29dB
-2.0dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
-10dBFS
-20dBFS
-30dBFS
-40dBFS
A/D IN
50mVrms
(-26.5dBFS)
AK5358B
200mVrms
H/POUT
277mVrms/33Ω
LEVEL DIAGRAM
FRONT ch
-12dB
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
200mV
+30dB
SP OUT
4.24Vrms/8Ω
GAIN setting of MASTER VOL 00dB
･SW:YES (DIGITAL) -2dB =-2.0dB
･SW:YES (ANALOG) -2dB+ 6.5dB=+4.5dB
･SW:NONE (DIGITAL) -2dB+12dB =10.0dB
･SW:NONE (ANALOG) -2dB+12dB+6.5dB=16.5dB
① ② ③
①:Basic OFFSET of VOL=0dB (indication value)
②:OFFSET of SW NON
③:OFFSET of AD input
-2+12=10.0dB
-2+12+6.5=16.5dB
-2+6.5=+4.5dB
SW NO
-32dBFS(DIG.IN)
-38.5dBFS(A/D IN)
-20dBFS(DIG.IN)
-26.5dBFS(A/D IN)
＋
＋
LINE IN
H/POUT
＋
SPEAKER
OUT
ANALOG
ATT
R2A15220FP
GAIN
ADJ.
AK4358VQ
D/A
－
－
＋
AK5358B
A/D
R2A15220FP ATT:0dB at AUTOSETUP
ACM2 (DM-A409)Sensitivity:
-38.8dBV/Pa = 11.48mV/Pa at 94dBSPL @Operation Voltage 5.0V (94dBSPL is expected to -
11.0dBFS)
MIC IN
11.48mVrms
AD IN=50mV
SINGLE INPUT
0dBFS=3Vpp
=1.06Vrms
AK4358VQ
DIFF.OUT
0dBFS=5Vpp
=1.77Vrms
+1.07dB
+1.07dB
AZ4580 MAX.OUTPUT 7.78Vrms
R2A15220FP MAX.OUTPUT 3.8Vrms
DOLBY LIMIT LEVEL (ALLch-3dBFS)
FULL SCALE LEVEL=2Vrms
MIC IN
＋
PLD
DSP
PREOUT
150mVrms

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
