Denon AVR-3312 Service Manual

201
PARTS LIST OF P.C.B. UNIT
s
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : Black model SP : Premium Silver model
PCB FRONT ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D2631289900 IC AZ4580MTR-E1
CVIAZ4580MTR-E1
IC607 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
Q6026 943219006820S TR KTC1027Y CVTKTC1027YT
Q6042 943214500020S TR 2SC3052 CVT2SC3052
Q6052 943214500020S TR 2SC3052 CVT2SC3052
Q6062 943214500020S TR 2SC3052 CVT2SC3052
Q6081 943216500020S TR RT1N141C CVTRT1N141C
Q6112 943215500020S TR RT1P141C CVTRT1P141C
Q6311,6312 943215500020S TR RT1P141C CVTRT1P141C
Q6313,6314 943216500020S TR RT1N141C CVTRT1N141C
Q6703 943216500020S TR RT1N141C CVTRT1N141C
D6021 90M-HD302360R DIODE ZJ6.8BT CVDZJ6.8BT
D6023,6024 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST
D6026 943202007690S DIODE , ZENER 18V CVDZJ18BT
D6027 00D9430087209 ZENER DIODE ZJ24B 1/2W CVDZJ24BT
D6041 943209001080S DIODE 1SS355T CVD1SS355T
D6051 943209001080S DIODE 1SS355T CVD1SS355T
D6061 943209001080S DIODE 1SS355T CVD1SS355T
D6712 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR
D6729,6730 00D2760694903 DIODE , ZENER (CHIP,5.1V) HVDUDZS5.1BSR
D6803 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1
D6835,6836 963209003510S DIODE , RELIABLE ESD PROTECTION CVDCDS3C05HDMI1
RESISTORS GROUP
z
R6024 943124500040S RES,M-OXIDEFILM(1W/4.7ohm)
CRG1SANJ4R7RT
CAPACITORS GROUP
C6021 00D9430175108 ELECT CAP 10UF 50V
CCEA1HH100T
C6022,6023 00MOF15104040 CAP,METAL-FILM(100V/0.1uF) CCME2A104JXT
C6024 943134501530S CAP , ELECT(63V/470uF) CCEA1JH471 *
C6025 943134010530S ELECT CAP 1UF 50V C
CCEA1HH1R0T
C6027 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C6031 nsp CAP, CHIP(1608, 50V/30pF) CCUS1H300JA
C6034 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6044 nsp COPPER WIRE C3A206
C6071-6073 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C6081 nsp CHIP CAP 0.1UF/50V/2012 CCUC1H104KC
C6082 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C6083 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C6084 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6113 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6114 nsp ELECT CAP 47UF 16V CCEA1CH470T
C6321 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6351,6352 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C6356 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6417 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C6423,6424 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C6425 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6501,6502 nsp CHIP CAP 1000PF 50VK CCUS1H102KC
C6503 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6512,6513 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C6514 943134501540S CAP , ELECT(50V/1uF)-S CCEA1HKS1R0T *

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
