Denon AVR-3312 Service Manual

3.5. Audiosystemconrmationitems
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of conrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Display:
A 0 1 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [7/PQRS]
e
KEY 7/PQRS (Main Zone)
Initialization & Amp assign NORMAL& Input
Mode Fixed ANALOG & SURROUND mode
DIRECT
8.Press [DVD]
r
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Display:
A 0 2 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (Front L/R)
·Input : Digital / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [8/TUV]
e
KEY 8/TUV (Main Zone)
Initialization & Amp assign NORMAL& Input
Mode Fixed DIGITAL
8.Press [DVD]
r
DVD (Main Zone)
3
DIGITAL (signal) Path
(ZONE2)
Input Mode : Fixed DIGITAL
Amp assign : ZONE2
ZONE2 Function : Source
Display:
A 0 3 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : Pre OUT(ZONE2 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
AVR2312: Only "NET/USB" corresponds to the input
source.
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [9/WXYZ]
e
KEY9/WXYZ (Main Zone)
Initialization & Amp assign ZONE2 & Input
Mode Fixed DIGITAL
8.Press [ZONE SELECT], Select "ZONE2"
9.Press [ZONE ON]
r
ZONE2 POWER ON
10.Press [ZONE SELECT], Select "MAIN"
11.Press [DVD]
t
DVD (Main Zone)
4
DIGITAL (signal) Path
(ZONE3)
Input Mode : Fixed DIGITAL
Amp assign : ZONE3
ZONE3 Function : Source
Display:
A 0 4 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : Pre OUT(ZONE3 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
only AVR3312
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [0/_*]
e
KEY 0/CODE2 (Main Zone)
Initialization & Amp assign ZONE3 & Input
Mode Fixed DIGITAL
8.Press [ZONE SELECT], Select "ZONE3"
9.Press [ZONE ON]
r
ZONE3 POWER ON
10.Press [ZONE SELECT], Select "MAIN"
11.Press [DVD]
t
DVD (Main Zone)
5
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Display:
A 0 5 D V D
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI / Output : Speakers (Front L/R)
·Input : HDMI / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [MOVIE]
e
MOVIE
Initialization &Amp assign NORMAL & Input
Mode Fixed HDMI
8.Press [DVD]
r
DVD (Main Zone)
26
g.10
g.11
g.12
g.13
g.14

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
