Denon AVR-3312 Service Manual

17
1. µcom/DSP Version display mode
1.1. Operationspecications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the "ON/STANDBY" button to turn on the power while pressing the "STATUS" and "PRESET CH +" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
b
When the version is displayed on the FL Display, the version list is also displayed on the OSD.
1.2. Display Order
Error information(Refer to 1.3. Error display) →
q
Model destination information →
w
Firmware Package Version
→
e
Main µ-com/MAIN FBL(1st Boot Loader) Version →
r
Sub µ-com/Sub FBL →
t
DSP version →
y
Audio PLD
→
u
GUI SFLASH →
i
Ethernet(DM860) 1st Boot Loader, Hardware ID
→
o
Ethernet(DM860) 2nd Boot Loader, Rhapsody Flag →
Q0
Ethernet(DM860) IMAGE
→
Q1
Ethernet(DM860)MAC ADDRESS information →
Q2
HD RADIO SDK/HD RADIO BBP(AVR-3312CIE3 only)
→
Q3
MultEQ Pro APP(Displayed when Audyssey Pro is complete)
→
Q4
MultEQ Pro ICL(Displayed when Audyssey Pro is complete
q
Model destination information :
Upper
A V R 3 3 1 2 E 3 : * * * *
Lower
S / N . * * * * * * * * * *
w
Firmware Package Version :
Upper
F i r m . P a c k a g e
Lower
V e r . : * * * *
e
Main µ-com & MAIN FBL version :
Upper
M a i n : * * . * *
Lower
M a i n F B L : * * . * *
r
Sub µ-com & Sub FBL :
Upper
S u b : * * . * *
Lower
S u b F B L : * * . * *
t
DSP ROM :
Upper
D S P : * * . * *
Lower
y
Audio PLD :
Upper
A u d i o P L D : * * . * *
Lower
u
GUI SFLASH :
Upper
G U I : * * * * * * * *
Lower

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
