Denon AVR-3312 Service Manual

208
PCB CNT ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC961 231310009508S
I.C , REGULATOR (3.3V) CVIPQ033DNA1ZPH
IC962 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC991 963239008800S I.C, RS232 DRIVER(3.3V) CVIILX3232DT
IC992,993 00D2631286903 I.C , REGULATOR (12V) CVIPQ120DNA1ZPH
D9903,9904 00D2760665903 DIODE , ZENER 16V CVDZJ16BT
D9905,9906 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP
CAPACITORS GROUP
C9601 nsp
CHIP CAP 0.1UF 50V K CCUS1H104KC
C9602-9605 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9607-9610 nsp CAP, CHIP(1608, 50V/33pF) CCUS1H330JA
C9611 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9612 nsp CHIP CAP 1UF 10V CCUS1A105KC
C9613 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9614 nsp CHIP CAP 1UF 10V CCUS1A105KC
C9615-9618 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9622 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9644-9646 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C9901 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9903-9905 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9906 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9907 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9908,9909 nsp CAP, CHIP(1608, 50V/33pF) CCUS1H330JA
C9916,9917 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9918,9919 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C9920,9921 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C9923,9924 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
OTHERS PARTS GROUP
CN21A nsp
PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN22A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-TO-B) CJP17GI281Z
CN23A nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z
CN24A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z
CN25A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-TO-B) CJP17GI281Z
CN26A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN27A nsp PIN HEADER (21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z
CN28A nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
CN41A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN42A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z
CN43A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN44A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-TO-B) CJP17GI281Z
CN45A nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
CN51A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z
CN52A nsp PIN HEADER (17P,1.25mm,STRAIGHT,B-TO-B) CJP17GI281Z
CN53A nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z
CN61B nsp PIN SOCKET (17P,1.25mm,ANGLE, B-TO-B) P CJP17HJ282Z
CN62B nsp PIN SOCKET (15P,1.25mm,ANGLE, B-TO-B) CJP15HJ282Z
CN63B nsp PIN SOCKET (17P,1.25mm,ANGLE, B-TO-B) P CJP17HJ282Z
CN64B nsp PIN SOCKET (21P,1.25mm,ANGLE, B-TO-B) CJP21HJ282Z
CN961 nsp WAFER CARD CABLE, 13PIN 1.25MM CJP13GA115ZY
CN97B nsp PIN SOCKET (15P,1.25mm,ANGLE, B-TO-B) CJP15HJ282Z
CN98B,99 nsp PIN SOCKET (11P,1.25mm,ANGLE, B-TO-B) CJP11HJ282Z
JK991 943646100420S JACK, D-SUB 9P (HDR-9PF-RSB) CJJ9W001Z
JK992,993 643010086019S JACK, STEREO (RED MOLD) CJJ2D019Z
JW901,902 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
