Denon AVR-3312 Service Manual

215
PCB VIDEO ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC551 235810046603S IC, AVDM2000 CVIAVDM2000
IC552,553 00D2622012908 IC, BU4052BCF CVIBU4052BCF
IC554-557 232810005504S IC, BD7628F CVIBD7628F
IC558 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
Q5101-5104 963212500030S T.R , ISA1530AC1 CVTISA1530AC1
Q5105-5107 943216500020S TR RT1N141C CVTRT1N141C
Q5108 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q5109-5112 943216500020S TR RT1N141C CVTRT1N141C
D5101-5108 90M-HZ200190R DIODE, SWITCHING, SMD TYPE HVDRLS4148SR
D5109 00D2760718902 DIODE, SCHOTTKY, 30V CVDRB521S-30
CAPACITORS GROUP
C5102 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5104 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5106 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5108 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5114 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5116 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5118 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5120 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5122 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5124 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5134 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5136 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5138 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5140 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5142-5145 00D9430062101 ELECT CAP 100UF 16V CCEA1CH101T
C5146 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5147 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5148 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5149 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5150 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5152 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5154 nsp
CHIP CAP 0.01UF 50V K CCUS1H103KC
C5155 nsp CHIP CAP 220PF 50V CCUS1H221JA
C5156 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5158-5161 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5162-5164 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5165 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5166-5169 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5170-5173 943134010530S ELECT CAP 1UF 50V C CCEA1HH1R0T
C5178-5181 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC
C5182-5189 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5190,5191 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5192-5201 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5202 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5203 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5204 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5205,5206 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C5209 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5210,5211 963134010980S ELECT CAP 47UF 16V CCEA1CH470T
C5212 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C5213 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5220-5222 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5223-5225 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5237-5240 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
RESISTORS GROUP
R5101-5108 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5110 nsp CHIP RES1%75OHM CRJ10DF75R0T

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
