Denon AVR-3312 Service Manual

213
PCB INPUT ASSY
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC466 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC471 235810045600S IC, R2A15220FP CVIR2A15220FP
IC481-483 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC484 00D2623727904 I.C, NJW1194V CVINJW1194V
IC486-488 00D2631289900 IC AZ4580MTR-E1 CVIAZ4580MTR-E1
IC489 00D2623727904 I.C, NJW1194V CVINJW1194V
D2397 943209001080S DIODE 1SS355T CVD1SS355T
D2399 943209001080S DIODE 1SS355T CVD1SS355T
D4779,4780 943203003150S DIODE 1N4007T CVD1N4007SRT
RESISTORS GROUP
z
R2396 252310006537S PTC THEMISTORS, CHIP(85'C)
CRTPRF18BE471QB5RB
R2397 nsp RES,CHIP(0OHM,5%,1608) CRJ10DJ0R0T
z
R2399 252310006537S PTC THEMISTORS, CHIP(85'C)
CRTPRF18BE471QB5RB
CAPACITORS GROUP
C4603,4604 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4607,4608 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4613,4614 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4617,4618 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4623,4624 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4627,4628 nsp CHIP CAP 330PF 50V J CCUS1H331JA
C4661,4662 nsp CHIP CAP 100PF 50V J E2,E1C CCUS1H101JA
C4663,4664 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4665,4666 nsp CHIP CAP 220PF 50V CCUS1H221JA
C4675,4676 00D9430173003 ELECT CAP 220UF10V CCEA1AH221T
C4677,4678 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C4679,4680 nsp CAP , MYLAR HCQI1H223JZT
C4681,4682 nsp CAP , MYLAR HCQI1H682JZT
C4687-4690 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4701,4702 00MOA10705020 ELECT CAP 100UF 50V CCEA1HH101T
C4705,4706 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C4710,4711 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C4713,4714 00D9430148708 ELECT CAP 47UF 50V CCEA1HH470T
C4727,4728 00D9430062101
ELECT CAP 100UF 16V E3,E1C CCEA1CH101T
C4727,4728 943134500060S ELECT CAP 100UF 50V E2 CCEA1HH101T
C4729,4730 00D9430175108 ELECT CAP 10UF 50V E3,E1C CCEA1HH100T
C4729,4730 943134500070S ELECT CAP 10UF 50V E2 CCEA2AH100T
C4761,4762 00D9430175108 ELECT CAP 10UF 50V E3,E1C CCEA1HH100T
C4761,4762 943134500070S ELECT CAP 10UF 50V E2 CCEA2AH100T
C4763-4768 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4773,4774 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4781-4784 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4801,4802 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4803-4806 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C4811,4812 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4819,4820 nsp CAP, CHIP(1608, 50V/68pF) CCUS1H680JA
C4823,4824 nsp CHIP CAP 100PF 50V J CCUS1H101JA
C4825-4828 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4831,4832 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4837,4838 nsp CAP, CHIP(1608, 50V/3300pF) CCUS1H332KC
C4839,4840 nsp CHIP CAP 0.1UF 50V K CCUS1H104KC
C4841,4842 943134010610S ELECT CAP 4.7UF 50V CCEA1HH4R7T
C4843 943134501580S CAP , ELECT(25V/33uF) CCEA1EH330T *
C4844 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4845 943134501580S CAP , ELECT(25V/33uF) CCEA1EH330T *
C4851,4852 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4853-4856 nsp CHIP CAP 0.01UF 50V K CCUS1H103KC
C4861,4862 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C4869,4870 nsp CAP, CHIP(1608, 50V/68pF) CCUS1H680JA
C4873,4874 nsp CHIP CAP 100PF 50V J CCUS1H101JA

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
