Denon AVR-3312 Service Manual

167
PARTS LIST OF PACKING & ACCESSORIES
s
z
Parts indicated by "nsp" on this table cannot be supplied.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
1 - set 1
2 nsp POLY BAG CPP1A081X 1
3 943533100960D SNOW, PAD L CPS1A905 1 *
4 943533100950D SNOW, CUSHION R CPS1A906 1 *
z
5 90M-ZC000310R CORD , POWER(PLUG+SOCKET)UL E3 CJA2A070Z 1
z
5 90M-ZC000320R CORD , POWER, EUR,10A,250V E2 CJA2B054Z 1
z
5 90M-ZC000650R CORD , POWER, 10A,125V E1C CJA2N075Z 1
6 - INSTRUCTION MANUAL ASS'Y - 1
6-1 352010044005D MANUAL, CD ASS'Y E3 CFT1A044ZA 1 *
6-1 352010045008D MANUAL, CD ASS'Y E2 CFT1A045ZA 1 *
6-1 352010053009D MANUAL, CD ASS'Y E1C CFT1A046ZA 1 *
6-2 nsp CARD, WARRANTY E3 CQE1A224Q 1
6-2 nsp CARD, WARRANTY E1C CQE1A473Y 1
6-3 nsp S.S LIST CQE1A226P 1
6-4 542110064009D MANUAL, GUIDE E3 CQX1A1624Z 1 *
6-4 542110065002D MANUAL, GUIDE E2 CQX1A1625Z 1 *
6-4 542110067008D MANUAL, GUIDE E1C CQX1A1626Z 1 *
6-5 307010087002D REMOCON ASS'Y(RC-1156) CARTAVR2312 1
6-6 nsp BATTERY(AA ) CABR6PPB 2
6-7 00D2310089007 ANT, AM LOOP(HD RADIO),105uH, 18T E3 CSA1A038Z 1
6-7 00D2310089007 ANT , AM LOOP(9.5uH, 5T) E2 CSA1A032Z 1
6-8 90M-ZA000230R FM 1 POLANT(UL) CSA1A019Z 1
6-9 nsp CARD FOR CHINA INDENTIFICATION E1C CQE1A450Z 1
6-10 nsp POLY BAG(MANUAL) CPB1A197Z 1
7 943531101830D BOX, OUT CARTON CIBKE3 CPG1A948W 1 *
7 943531101850D BOX, OUT CARTON BKE2 CPG1A948V 1 *
7 943531101870D BOX, OUT CARTON SPE1C CPG1A948U 1 *
8 nsp CONTROL LABEL CQB1A993Z 1
9 nsp COLOR LABEL SPE1C CQB1A676 2
10 324010001003D DM-A409EM CJXAVR1612A 1
11 nsp LABEL, LICENSE CQB1A1061Z 1
★
12 nsp PESHEET CPE1D001 1
★
13 nsp LABEL BARCODE(SET) CQB1A978 1
★
14 nsp RIBON BARCODE CQS1A001 1
★
15 nsp BARCODE LABEL(MANUAL) CQB1A971 1
g

Denon AVR-3312 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.8 %
Power output per channel (1KHz@8 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Audio (L/R) in	8
Composite video in	5
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Composite video out	3
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFL
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W
Card reader integrated	-
Cables included	AC

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11800 g
