163

PARTS LIST OF EXPLODED VIEW

Parts indicated by "nsp" on this table cannot be supplied.

P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.

Parts indicated by the "

★

" mark are not illustrated in the exploded view.

The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.

Note:

The symbols in the column "Remarks" indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model

E1C : China model EA : Australia model

BK : Black model SP : Premium Silver model

Ref. No. Part No. Part Name Remarks Q'ty New

1 nsp PCB FRONT ASSY E3,E2 COP12384B 1 *

1 nsp PCB FRONT ASSY E1C COP12384D 1 *

C1 - PCB V.AUX_VOL -

C2 - PCB HP -

C3 - PCB USB -

C4 - PCB FRONT -

C5 - PCB SELECTOR -

C6 - PCB HDMI FFC GUIDE -

C7 - PCB GUIDE R -

C8 - PCB GUIDE L -

C9 - PCB GUIDE TOP -

C10 nsp PCB 7CH_AMP ASSY E3,E2 COP12385B 1 *

C10 nsp PCB 7CH_AMP ASSY E1C COP12385D 1 *

2 nsp PCB CNT ASSY E3 COP12387B 1 *

2 nsp PCB CNT ASSY E2 COP12387C 1 *

2 nsp PCB CNT ASSY E1C COP12387D 1 *

C11 - PCB FRONT CNT -

C12 - PCB SIDE CNT -

C13 - PCB RS232C -

3 nsp PCB MAIN ASSY E3 COP12386B 1 *

3 nsp PCB MAIN ASSY E2 COP12386C 1 *

3 nsp PCB MAIN ASSY E1C COP12386D 1 *

C14 - PCB SPK_PREOUT -

C15 - PCB RS232C CNT -

C16 -

PCB FUSE -

C17 - PCB F_WIDE -

4 nsp PCB INPUT ASSY E3 COP12388B 1 *

4 nsp PCB INPUT ASSY E2 COP12388C 1 *

4 nsp PCB INPUT ASSY E1C COP12388D 1 *

C18 - PCB INPUT -

C19 - PCB POSISTOR -

C20 nsp PCB VIDEO ASSY E3,E2 COP12389B 1 *

C20 nsp PCB VIDEO ASSY E1C COP12389D 1 *
