DITEC LCA70 User Manual

28
IP2368EN
EN
11.6.1 Additional configurable SF level parameters available with
→
enabled
Display Description
SP - Setting the password
ENTER UP DOWN
2”
ENTER
[esempio]
→→
/
→→→
NOTE: this can only be selected when the password is not set.
Setting the password prevents unauthorised personnel from accessing selections and adjust-
ments. You can delete the set password by selecting the sequence JR1=ON, JR1=OFF, JR1=ON.
IP - Inserting the password
ENTER UP DOWN
2
”
ENTER
[esem
p
io]
→→
/
→→→
NOTE: this can only be selected when the password is set.
When the password is not inserted, you can access the display mode regardless of the selection
made with JR1. When the password is inserted, you can access in maintenance mode.
EU - Deletion of user configurations and last configuration set (can be called up from )
→
→→
2”
ENTER
2”
ENTER
AL - Alarm counter
Used to view, in sequence, the counters of alarms that have been triggered at least once (alarm
code + number of times triggered).
With UP and DOWN, you can scroll through all the counters and see all the alarms recorded.
AH - Alarm log
Used to view, in sequence, alarms that have been triggered (up to a maximum of 20).
With UP and DOWN, you can scroll through the entire alarm log.
The display shows the alarm number and code, alternated.
The highest number corresponds to the most recent alarm and the lowest number (0) corre-
sponds to the oldest alarm.
AR - Alarm reset
Resets all the alarms in the memory (counters and log).
→
2”
ENTER
NOTE: when the installation has been completed, you are advised to delete the alarms
in order to facilitate future checks.
TT - Display of min/max temperatures recorded
- press for 2 sec to reset the values;
- minimum value with active right decimal point.
UP - Firmware update
Activates the card bootloader in order to update the firmware.
→
2”
ENTER
SF - Special functions
[example]
[example]
