Ducati MONSTER S2R 1000 User Manual

21
E
Left-hand handlebar switch (fig. 11)
1) Dip switch, two-position light selector switch:
position = low beam on;
position = high beam on.
2) Button = three-position turn signal:
centre position = off;
position = left turn;
position = right turn.
To cancel the turn signals, press the control switch once it
has returned to the central position.
3) Button = horn.
4) Button = high beam flasher.
Clutch lever (fig. 11)
Lever (5) disengages the clutch. It features an adjuster
knob (6) to alter the distance of the lever from the
twistgrip on handlebar.
To make the adjustment, keep the lever (5) full forward and
adjust the knob (6), turning it to one of the four preset
positions, taking account of the fact that:
position n° 1 corresponds to the maximum distance
between the lever and grip, while position n° 4
corresponds to the minimum distance.
When the clutch lever (5) is operated, drive from the
engine to the gearbox and the rear wheel is disengaged.
Correct use of the clutch lever is very important in all
riding situations, especially when moving off.
Important
Using the clutch properly will prolong the life of the
engine and prevent any damage to components in the
transmission.
Notes
The engine can be started with the sidestand down
and the gearbox in neutral. If starting with a gear engaged,
pull in the clutch lever (in this case the sidestand must be up).
1
5
4
6
2
3
fig. 11

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
