Ducati MONSTER S2R 1000 User Manual

63
E
Checking the engine oil level (fig. 58)
The engine oil level can be seen through the sight glass (1)
on the clutch cover.
Check the oil level with the motorcycle upright and the
engine cold. Allow a few minutes for the oil level to stabilize
after stopping the engine.
The oil level should be between the marks next to the
sight glass. If the level is below the bottom mark, top up
with SHELL Advance Ultra 4 engine oil.
Remove the oil filler cap (2) and top up until the oil reaches
the required level. Replace the filler cap.
Important
To change the engine oil and filters at the intervals
specified in the maintenance table in the Warranty Booklet,
contact a Ducati dealer or Authorized Service Centre.
Oil viscosity
SAE 10W-40
The other viscosity values shown in the table can be used if
the local average temperature is within the limits specified
for that oil viscosity.
1
2
fig. 58
–10
Unigrade
Multigrade
0 10 20 30 40 C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
