Ducati MONSTER S2R 1000 User Manual

53
E
Charging the battery (fig. 46)
Before charging the battery, it is best to remove it from
the motorcycle.
First disconnect the black negative terminal (-), then the
red positive terminal (+).
Release the clips (1) and remove the battery.
Warning
The battery produces explosive gases: keep it away
from heat sources and flames.
Charge the battery in a well-ventilated area.
Connect the battery charger leads to the battery terminals: red
to the positive terminal (+), black to the negative terminal (-).
Important
Connect the battery to the charger before switching
on to prevent sparks at the battery terminals that could
ignite the gases inside the cells.
Always connect the red positive terminal first.
Warning
Keep the battery out of the reach of children.
Charge the battery at 1 A for 5 to 10 hours.
1
-
+
fig. 46

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
