Ducati MONSTER S2R 1000 User Manual

78
E
Exhaust system
Equipped with catalytic converter in compliance with Euro 3
emission regulations.
Available colours
Ducati anniversary red, code F_473.101 (PPG);
Transparent, code 228.880 (PPG)
with white stripe
Red frame with black wheels.
Metallic dark grey, code *0022 (PPG);
Transparent, code 228.880 (PPG)
with black stripe;
Black frame and wheels.
Gloss black, code 248.514 (PPG);
Transparent, code 228.880 (PPG)
with white stripe
Black frame with black wheels.
Electrical system
The main components of the electrical system are:
front headlight:
bulb type: H4 (12 V-55/60 W).
side light:
bulb type: T4W (12 V-4 W).
Electrical controls on handlebars:
turn signals:
bulb type: R10W (12 V-10 W).
Horn
Brake light switches.
Battery, 12 V-16 Ah.
Alternator, 12 V-520 W.
Electronic voltage regulator (rectifier), protected by a 30 A
fuse near the battery.
Starter motor, 12 V-0.7 kW.
Tail light and brake light:
bulb type: P21/5W (12 V-5/21 W).
Number plate light:
bulb type: W5W (12 V-5 W).
Notes
To replace the bulbs, refer to the paragraph
“Changing the bulbs” on page 56.

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
