Ducati MONSTER S2R 1000 User Manual

25
E
Adjusting the position of the gearchange
pedal (fig. 16)
The position of the gearchange pedal relative to the footrest
can be adjusted to suit the requirements of the rider.
To adjust the position, proceed as follows:
Hold the rod (1) using an open-ended wrench (2) and
slacken off the locknuts (3) and (4).
Notes
The locknut (4) has a left-hand thread.
Turn the rod (1) and move the pedal to the required position.
Tighten both nuts against the rod.
31
2
4
fig. 16

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
