Ducati MONSTER S2R 1000 User Manual

51
E
Lubricating cables and joints (fig. 44)
The condition of the outer cables of the throttle and starter
cables should be checked at regular intervals. There should be
no signs of pinching or cracking on the outer plastic sheath.
Operate the control to check that the inner cable slides
smoothly: if you feel any rubbing or catching, have the cable
replaced by a Ducati Dealer or Authorized Service Centre.
To prevent problems, periodically lubricate the ends of each
control cable with SHELL Advance Grease or Retinax LX2.
In the case of the throttle cable, open the twistgrip housing
by unscrewing the two screws (1, fig. 44) and grease the
end of the cable and the race.
Warning
Close the twistgrip housing carefully, inserting the
cable in the race.
Refit the housing and tighten the screws (1) to 1.8 Nm.
To ensure smooth operation of the pivot on the sidestand,
remove any dirt and apply SHELL Alvania R3 to all points
subject to friction.
1
fig. 44

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
