Ducati MONSTER S2R 1000 User Manual

24
E
Rear brake pedal (fig. 14)
Push down on the pedal (1) with your foot to operate the
rear brake.
The system is controlled hydraulically.
Gearchange pedal (fig. 15)
The gearchange pedal has a central position N, with
automatic return, and two directions of movement:
down = push down on the pedal to engage 1
st
gear and
to shift down. At this point the N warning light on the
instrument panel will go off;
up = lift the pedal to engage 2
nd
gear and then 3
rd
, 4
th
,
5
th
and 6
th
gears.
Each time you move the pedal you engage the next gear,
one gear at a time.
1
fig. 14
6
5
4
3
2
1
N
fig. 15

Ducati MONSTER S2R 1000 Specifications

General

Displacement	992 cc
Bore x Stroke	94 mm x 71.5 mm
Compression Ratio	10:1
Power	95 hp (69.9 kW) @ 8000 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Cooling	Air cooled
Transmission	6-speed
Frame	Tubular steel trellis frame
Front Brake	2 x 320 mm discs, 4-piston calipers
Rear Brake	245 mm disc, 2-piston caliper
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Seat Height	800mm (31.5 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Final Drive	Chain
Front Suspension	Showa 43mm upside-down fork
Rear Suspension	Progressive with preload and rebound Sachs adjustable monoshock
Fuel Capacity	14 liters (3.7 gallons)
